Fabtech 1-1.5" Lift Kit with Bilstein Front Shocks – Fits 2015-22 Mercedes Sprinter 3500 4WD

Straight answers

• Fits: 2015-22 Mercedes Sprinter 3500 4WD. Check the vehicle fitment below before you order.
• Drivetrain: 4WD only.
• Fitment notes: Some trims have conditions (wheels, control arms, ride-control options); see the vehicle fitment list below.
• Front Lift Amount: 1 To 1-1/2 Inch.
• Rear Lift Amount: 1 To 1-1/2 Inch.
• Maximum Tire Size: 32 x 11.00.
• Front Lift Type: Coil Spring Spacer.
• Rear Lift Type: Lift Blocks And U-Bolts.
• Shock Type: Hydraulic.
• Wheel Backspacing: 2.16 To 8 in.
• Minimum Wheel Diameter: 16.
• Shocks: With Front Bilstein And Rear Performance Shock Absorbers.
• Color: Black.

Not sure it fits your truck? Call (806) 621-1226 before you order and we'll check the fit for your year, make, model and drivetrain.

The front suspension of a Sprinter van utilizes a MacPherson strut to provide damping. The stock struts leave a lot to be desired on their own once you upfit the van for overland use or haul cargo. Fabtech offers a solution to this problem by utilizing a Bilstein strut with their high-quality cold wound coil spring. The coil springs are positioned around the strut bodies. They provide an additional lift to the vehicle of 1 Inch to 1-1/2 Inch over stock. This creates increased ground clearance and clearance of larger tires for off-road use. Additionally, they help reduce sway for vans with full interior build-outs or hauling heavy cargo. The coil springs utilize billet aluminum upper and lower coils seats that slide over the strut. They are positioned to the correct ride height and create a secure mounting for the springs. To further enhance the vehicle's suspension Fabtech recommends their Auxiliary Front Shock Mounts with Dirt Logic 2.25 shocks for a complete upgrade. This combination will help improve the ride characteristics of the vehicle well beyond stock. It will provide a very compliant highway ride while improving performance for off-highway use.

Features

• High-Quality Cold-Wound Coil Springs For Longevity And Ride Quality
• Billet Aluminum Upper And Lower Coils Seats Properly Locate The Coil Springs
• Increases Ride Height For More Ground Clearance And Helps Reduce Body Sway
• Can Be Paired With Fabtech Auxiliary Shock Mounts And Dirt Logic 2.25 Shocks For A Complete Upgrade
• Retains Factory Travel And Alignment
• Limited Lifetime Warranty

Specifications

• Brand: Fabtech
• Part Number: K9007
• Type: Lift Kit Suspension

Vehicle Fitment

• 2015-2022 Mercedes-Benz Sprinter 3500 – 4WD
  Note: 2015 Mercedes-Benz Sprinter 3500; 2016 Mercedes-Benz Sprinter 3500; 2017 Mercedes-Benz Sprinter 3500; 2018 Mercedes-Benz Sprinter 3500; 2019 Mercedes-Benz Sprinter 3500; 2020 Mercedes-Benz Sprinter 3500; 2021 Mercedes-Benz Sprinter 3500; 2022 Mercedes-Benz Sprinter 3500
